CPU INTEL i5-10400 2,9GHz, SIX CORE, 12MB s.1200 BOX, BX8070110400

Essentials

Product Collection            10th Generation Intel® Core™ i5 Processors

Code Name         Products formerly Comet Lake

Vertical Segment              Desktop

Processor Number           i5-10400

CPU Specifications

# of Cores            6

# of Threads       12

Processor Base Frequency            2.90 GHz

Max Turbo Frequency     4.30 GHz

Cache    12 MB Intel® Smart Cache

Bus Speed           8 GT/s

Intel® Turbo Boost Technology 2.0 Frequency‡    4.30 GHz

TDP        65 W

Supplemental Information

Embedded Options Available       No

Memory Specifications

Max Memory Size (dependent on memory type) 128 GB

Memory Types  DDR4-2666

Max # of Memory Channels         2

Max Memory Bandwidth              41.6 GB/s

ECC Memory Supported ‡             No

Processor Graphics

Processor Graphics ‡       Intel® UHD Graphics 630

Graphics Base Frequency              350 MHz

Graphics Max Dynamic Frequency             1.10 GHz

Graphics Video Max Memory      64 GB

4K Support          Yes, at 60Hz

Max Resolution (HDMI)‡               4096 x 2160@30Hz

Max Resolution (DP)‡     4096 x 2304@60Hz

Max Resolution (eDP – Integrated Flat Panel)‡     4096 x 2304@60Hz

DirectX* Support              12

OpenGL* Support            4.5

Intel® Quick Sync Video Yes

Intel® InTru™ 3D Technology        Yes

Intel® Clear Video HD Technology              Yes

Intel® Clear Video Technology     Yes

# of Displays Supported ‡              3

Device ID             0x9BC8 / 0x9BC5

Expansion Options

Scalability            1S Only

PCI Express Revision        3

PCI Express Configurations ‡        Up to 1×16, 2×8, 1×8+2×4

Max # of PCI Express Lanes           16

Package Specifications

Sockets Supported           FCLGA1200

Max CPU Configuration 1

Thermal Solution Specification    PCG 2015C

TJUNCTION        100°C

Package Size       37.5mm x 37.5mm

Advanced Technologies

Intel® Optane™ Memory Supported ‡      Yes

Intel® Thermal Velocity Boost      No

Intel® Turbo Boost Max Technology 3.0 ‡                No

Intel® Turbo Boost Technology ‡ 2

Intel vPro® Platform Eligibility ‡  No

Intel® Hyper-Threading Technology ‡       Yes

Intel® Virtualization Technology (VT-x) ‡  Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes

Intel® VT-x with Extended Page Tables (EPT) ‡       Yes

Intel® Transactional Synchronization Extensions  No

Intel® 64 ‡           Yes

Instruction Set   64-bit

Instruction Set Extensions            Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States           Yes

Enhanced Intel SpeedStep® Technology  Yes

Thermal Monitoring Technologies             Yes

Intel® Identity Protection Technology ‡   Yes

Intel® Stable Image Platform Program (SIPP)        No

Security & Reliability

Intel® AES New Instructions         Yes

Secure Key          Yes

Intel® Software Guard Extensions (Intel® SGX)     Yes with Intel® ME

Intel® OS Guard Yes

Intel® Trusted Execution Technology ‡     No

Execute Disable Bit ‡       Yes

Intel® Boot Guard             Yes
