MB GIGABYTE H610M H V2 REV. 1.0

MB GIGABYTE H610M H V2 REV. 1.0

Варијанта:

− +

4 290 ден.

0 ден.

Не е достапен

Бренд:

Gigabyte
Артикл:

INS-38-6452-E
Достапен за порачка:

Не е достапен

Да
Број на физички јадра:

6 , 4
Chipset:

Intel H610
RAM type:

DDR5
RAM DIMMs:

2
Капацитет:

128GB
USB Type-C ports:

1
Dimensions:

223mm x 196mm
Format:

Microatx
Note:

High Definition
Warranty:

36 months
Supported technologies:

Easy tuna, Smart Backup, UEFI BIOS
HDMI connectors:

1x HDMI 2.1
Model:

Realtek
Processor bearing (Socket):

Intel 1700
USB ports:

4x USB 2.0, 2x USB 5GBPS (3.2 Gen 1)
Other traits:

Support for Unbuffered ECC memory, Extreme Memory Profile Support (XMP), Dual Channel (Dual-Channel) Memory mode, Support for non-ECC Udimm Memory
Audio:

1x Front Panel Header, 1x Speaker Header
Wired network standards:

1000Base-T (Gigabit)
Other connections:

1 x Front Panel Header, 1x System Fan Header, 1 x Trusted Platform Module (TPM), 4 x SATA 6Gb / s, 1 x CPU Fan Header, 1x Chassis Intrusion Header, 1x M.2 Socket 3
PCI Express X1 Slot:

1x PCI Express 3.0
USB:

2 x Support for 1 USB 2.0 port, 1 x Support for 1 USB 5Gbps port
Supported memory:

5.600mt / s, 5,200mt / s, 4.800mt / s, 4.400mt / s
PCI Express x16 slot:

1x PCI Express 4.0 (x16 mode)
SATA ports:

SATA III 6GBPS
Channel number:

8 (7.1)
PS / 2:

1 (keyboard or mouse)
Voltage connections:

1x 24-pin ATX Main Power Connector, 1 x 8-pin ATX 12V Power Connector
Supported M.2 formats:

1x 2260/2280 (PCIE Support 3.0 X4X2 MOD)

Начин на испорака

Бесплатна достава во градско подрачје на Скопје за нарачка со вредност поголема од 10000 денари
Подигнување од нашата продавница

Начин на плаќање

Плаќање при подигнување
Фактурно плаќање

Сподели:

Basic characteristics - Socket: Intel 1700 Chipset: Intel H610 Memory: DDR5 Memory slots: 4.400mt / s, 4.800mt / s, 5.2mt / s, 5.600mt Maximum Memory: Double-channel (dual-channel) Memory mode Extreme Memory Profile (XMP), Non-ECC Support, Support for Unbuffered ECC Memory - PCI Express 4.0 (X16 Mode) PCI Express X1 Slot: 1x PCI Express 3.0 Storage Interface - SATA Connections (Total): SATA III 6GBPS Number M.2 Slots: 1 Supported M.2 Formats: 1x2260/2280 Model: 1000Base-T (gigabit) Model: Realtek Note: HGMI connections: 1 HDMI connectors: 1x HDMI 2.1 PS / 2: 1 (Keyboard or Mouse) Total USB ports: 6 USB 5GBPS (3.2 GEN 1), 4x 3.5mm Other connections: 1x D-SUB PORT INTERIOR POINTS - Voltage connections: 1 x 8-pin ATX 12V Power Connector, 1x 24-pin ATX Main Power Connector USB: 1 x Support for 1 USB 5Gbps port, 2 x Support for 1 USB 2.0 Speaker Header Serial port: 1 Other connectors: 1 x Clear CMOS Jumper, 1 x CPU Fan Header, 1 x Front Panel Header, 1 x RGB LED Strip Header, 1 X Trusted Platform Module (TPM), 1x Chassis Intrusion Header, 4 x SATA 6GB / s Other features - Supported technologies: Easy tuna, Smart Backup, UEFI Microatx Dimensions: 223mm x 196mm Complastic period - Complaint period: 36 months
