Тип на меморија:
DDR4
Број на физички јадра:
4
Chipset:
Intel B760
RAM DIMMs:
2
m.2:
5
Капацитет:
128GB
USB Type-C ports:
1
Dimensions:
244mm x 244mm
Format:
Microatx
Note:
High Definition
Warranty:
36 months
Supported technologies:
Q-Flash Plus, UEFI BIOS
DisplayPort ports:
1x DisplayPort 1.2
HDMI connectors:
1x HDMI 2.1
Model:
Realtek
Processor bearing (Socket):
Intel 1700
USB ports:
2x USB 2.0, 3x USB 5Gbps (3.2 Gen 1)
Other traits:
Support for Unbuffered ECC memory, Extreme Memory Profile Support (XMP), Dual Channel (Dual-Channel) Memory mode, Support for non-ECC Udimm Memory
Audio:
1x Front Panel Audio, 1x Front Panel Header
Wired network standards:
1000Base-T (Gigabit)
Other connections:
1 x Clear CMOS Jumper, 1 x Trusted Platform Module (TPM), 1 x SATA 6GB / S, 1 x RGB LED Header, 1 x Reset Jumper, 1 x CPO Fan Header, 1 x Addressable LED Strip Headers, 2 x M.2 Socket 3, 3 X System Fan Headers
PCI Express X1 Slot:
2x PCI Express 3.0
USB:
2 x Support for 1 USB 2.0 port, 1 x Support for 1 USB 5Gbps port
Supported memory:
3.200mt / s, 3.000mt / s, 2.933mt / s, 2.666mt / s, 2.400mt / s, 2.133mt / s, 5.333mt / s (O.C.), 5.8mt / s (O.C.), 4.600mt / s (O.C.), 4.400mt / s (O.C.), 4.266mt / s (O.C.), 4.000mt / s (O.C.), 3.733mt / s (O.C.), 3.400mt / s (O.C.), 3,333mt / s (O.C.), 4,133mt / s (O.C.), 3.800mt / s (O.C.), 4.933mt / s (O.C.), 4,300mt / s (O.C.), 5,100mt / s (O.C.), 3.800mt / s (O.C.), 4,500mt / s (O.C.), 3.66mt / s (O.C.), 4.700mt / s (O.C.)
PCI Express x16 slot:
1x PCI Express 4.0 (x16 mode)
SATA ports:
SATA III 6GBPS
Raid:
Raid 0, Raid 1, Raid 5, Raid 10
Channel number:
8 (7.1)
PS / 2:
1 (keyboard or mouse)
Voltage connections:
1x 24-pin ATX Main Power Connector, 1 x 8-pin ATX 12V Power Connector
USB-C:
1 x Support for 1 USB 5Gbps port
Supported M.2 formats:
2x 2280/22110 (PCIE 4.0 X4 / X2 mod)
