MSI Pro B760M-P DDR4

Варијанта:

− +

5 690 ден.

0 ден.

Не е достапен

Бренд:

MSI
Шифра:

INS-38-4452-E
Достапен за порачка:

Не е достапен

Да
Тип на меморија:

DDR4
Број на физички јадра:

6 , 4
Chipset:

Intel B760
RAM DIMMs:

2
Капацитет:

128GB
USB Type-C ports:

3 , 1
Модел:

Realtek ALC897 Codec
Dimensions:

243.84mm x 243.84mm, 243mm x 243mm
Format:

Microatx
Note:

To use certain internal connectors, additional brackets or connectors on the housing are required
Warranty:

36 months
Supported technologies:

Core Boost, Memory Boost
DisplayPort ports:

1x DisplayPort 1.4
HDMI connectors:

1x HDMI 1.4
Condition:

Unused
Package:

SATA Cable
Processor bearing (Socket):

Intel 1700
USB ports:

1x USB 5GBPS (3.2 GEN 1), 4x USB 2.0
Other traits:

Support for Extreme Memory Profile (XMP), Dual Channel (Dual-Channel) Memory mode, Non-ECC Support Udimm Memory
Audio:

1x Front Panel Audio
Wired network standards:

1000Base-T (Gigabit)
Other connections:

1x TPM Header, 2x System Fan Header, 1x CPU Fan, 2x Front Panel (JFP), 1x Chassis Intrusion (JCI), 1x RGB LED Connector (JRGB)
PCI Express X1 Slot:

2x PCI Express 4.0
USB:

2 x Support for 1 USB 10Gbps port
USB-C ports:

1x USB 10GBPS (3.2 GEN 2)
Supported memory:

2.133MHz, 3,333MHz (O.C.), 2.400MHz, 3.600MHz (O.C.), 3.400MHz (O.C.), 3.400MHz (O.C.), 4.000MHz (O.C.), 2.666MHz, 4,266MHz (O.C.), 4.400MHz (O.C.), 4,200MHz (O.C.), 2,933MHz, 4,600MHz (O.C.), 4,800MHz (O.C.), 3,200MHz, 3.800MHz (O.C.)
PCI Express x16 slot:

1x PCI Express 4.0 (x16 mode)
SATA ports:

SATA III 6GBPS
Raid:

Raid 0, Raid 1, Raid 5, Raid 10
Channel number:

8 (7.1)
PS / 2:

2 (keyboard + mouse)
Voltage connections:

1 x 24 PIN ATX Power Connector, 1 x 8-pin ATX 12V Power Connector

Начин на испорака

Бесплатна достава во градско подрачје на Скопје за нарачка со вредност поголема од 10000 денари
Подигнување од нашата продавница

Начин на плаќање

Плаќање при подигнување
Фактурно плаќање

Сподели:

Basic characteristics - Socket: Intel 1700 Chipset: Intel B760 Memory: DDR4 Memory slots: 4 Supported memory: 2.133MHz, 2.400MHz, 2.666MHz, 3.333MHz (o.c.), 3.400MHz (O.c.), 3.466MHz (O.c.), 3,600MHz (O.C.), 3.800MHz (O.C.), 4,000MHz (O.C.), 4,200MHz (O.C.), 4,400MHz (O.C.), 4.800MHz (O.c.) Maximum total memory: 128GB Other features: Double-channel (Dual-Channel) Support for Extreme Memory Profile (XMP), PCI Express X16 Support: 1x PCI Express 4.0 (X16 Mode) PCI Express 4.0 PCI Slot: 3 Storage Interface - SATA Connections (Total): SATA III 6GBPS: RAID 0, RAID 1, RAID 10, RAID: 1000Base-T (Gigabit) Model: Realtek Audio - Channel number: Realtek Alc897 Codec Note: Audio Boost Last panel connections - DisplayPort ports: 1 DISPLAYPORT 1.4 HDMI ports: 1 HDMI 1.4 VGA D-Sub: 1 PS / 2: 2 (keyboard + mouse) Total USB connectors: 1 USB ports: 1x USB 5GBPS (3.2 gene 1), 4x USB 2.0 USB-C connections: 1x USB 10GBPS (3.2): 1 Audio: 3x 3.5mm Internal connections - Voltage connections: 1 x 24 PIN ATX Power Connector, 1 x 8-pin ATX 12V Power Connector USB 10Gbps port audio: 1x Front Panel Audio Serial Port: 1 Parallel port: 1 other ports: 1x Chassis Intrusion (JCI), 1x RGB LED Connector (JRGB), 1x TPM Header, 2x System Fan Header Note: For utilization of certain internal connectors, additional Bracket or Accessories on the Core Features - Supported technologies: Core Boost, Memory Boost Physical Features - Format: Microatx Dimensions: 243.84mm x 243mm Packaging: SATA Cable Care: Unused Commercial Period - Commercial Period: 36 months
