ASUS ROG CROSSHAIR X670E HERO

ASUS ROG CROSSHAIR X670E HERO
 AMD Socket AM5 for AMD Ryzen 7000 Series Desktop Processors
 Chipset: AMD X670
 Memory: 4 x DIMM
 Max. 128GB
 DDR5
 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800MHz
 Un-buffered Memory
 Dual Channel Memory Architecture
 Supports AMD Extended Profiles for Overclocking (EXPO)
 OptiMem II
 Graphics: 1 x HDMI port
 2 xUSB4 ports support USB Type-C display outputs
 Expansion Slots: AMD Ryzen 7000 Series Desktop Processors
 2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 mode(s)
 AMD X670 Chipset: 1 x PCIe 4.0 x1 slots
 Storage: Total supports 5 x M.2 slots and 6 x SATA 6Gb/s ports
 AMD Ryzen 7000 Series Desktop Processors
 M.2_1 slot (Key M)
 type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
 M.2_2 slot (Key M)
 type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
 PCIe 5.0 M.2 slot (Key M) via PCIe 5.0 M.2 card
 type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)
 AMD X670 Chipset: M.2_3 slot (Key M)
 type 2242/2260/2280 (supports PCIe 4.0 x4 )
 M.2_4 slot (Key M)
 type 2242/2260/2280 (supports PCIe 4.0 x4 )
 6 x SATA 6Gb/s ports
 Ethernet: 1 x Intel 2.5Gb Ethernet
 ASUS LANGuard
 Wireless & Bluetooth: Wi-Fi 6E
 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
 Supports 2.4/5/6GHz frequency band
 Bluetooth v5.3
 USB: Rear USB (Total 12 ports): 2 x USB4 ports with Intel JHL8540 USB4 controller (2 x USB Type-C)
 1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C)
 9 x USB 3.2 Gen 2 port(s) (8 x Type-A + 1 x USB Type-C)
 Front USB (Total 11 ports)
 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C with up to 60W PD/QC4+)
 2 x USB 3.2 Gen 1 headers) support additional 4 USB 3.2 Gen 1 ports
 3 x USB 2.0 headers support additional 6 USB 2.0 ports
 Audio: ROG SupremeFX 7.1 Surround Sound High
 Definition Audio CODEC ALC4082
 Back Panel I/O Ports: 2 x USB4 ports with Intel JHL8540 USB4
 controller (2 x USB Type-C)
 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C)
 9 x USB 3.2 Gen 2 ports(8 x Type-A + 1 x Type-C)
 1 x HDMI port
 1 x Wi-Fi Module
 1 x Intel 2.5Gb Ethernet
 5 x Gold-plated audio jacks
 1 x Optical S/PDIF out port
 1 x BIOS FlashBack button
 1 x Clear CMOS button
 90MB1BC0-M0EAY0
